Rib-Type Roofing

Description

SUBSTRATES
Hot-dip Metallic Coated Steel
-Hot-dip Zinc-Coated Steel
-Hot-dip 55% Aluminum-Zinc Alloy Coated Steel

NOMINAL THICKNESS
0.30 mm to 0.60 mm (Up to 0.80 mm upon request)

FEED WIDTH
915 mm and 1220 mm

EFFECTIVE COVERAGE
780mm and 1070mm (+/- 10mm)

RIB HEIGHT
22 mm

PAINT COATING SYSTEM
Oven baked Oil free Polyester topcoat over a corrosion-resistant Primer with Oil free Polyester backing coat PVDF, SMP, available upon request

PAINT COATING
Topcoat: 12-15 microns

THICKNESS
Backing Coat: 4-8 micron

LENGTH
8,10, 12 feet standard
Customized length available with terms and condition
Onsite roll forming for longer panels
